Precise localization Self Piercing Busbar Riveting Machine
Equipment data on self-piercing riveting machine
| No. | Parameters |
| Model | KD-MJQ-2 |
| Max. Pressure | 250MPa |
| Oil Pipe Length | 10000mm |
| Oil Tank Capacity | 50L |
| Gun Head Stroke | 50mm |
| Aluminum Thickness | 3mm+3mm |
| Iron Thickness | 1.5mm+1.5mm |
| Power | 380~415VAC 50~60Hz 4.5kW |
Function introduction
Self-piercing riveting machine, also called riveting gun, is applied for busbar assembly. It can be customized according to different busbar housing. Before riveting, operator does not need to drill the hole. Machine can realize self-piercing riveting by its pressure and rivet structure. Working principal is as below.
Advantage
1) Automatic feeding
2) Precise localization, low NG rate
3) Pneumatic power
4) Customize available
